CODE 1
type: custom:sunsynk-power-flow-card
cardstyle: lite
show_solar: ‘yes’
battery:
energy: 6400
shutdown_soc: 10
show_daily: ‘yes’
invert_power: ‘yes’
solar:
show_daily: ‘yes’
mppts: two
pv1_name: Back
pv2_name: Front
load:
show_daily: ‘yes’
grid:
show_daily_buy: ‘yes’
show_daily_sell: ‘yes’
show_nonessential: ‘no’
invert_grid: ‘yes’
entities:
day_pv_energy_108: sensor.lux_baxxxxxxx_solar_output_daily
inverter_voltage_154: sensor.lux_baxxxxxxx_grid_voltage_live
load_frequency_192: sensor.lux_baxxxxxxx_grid_frequency_live
inverter_current_164: none
inverter_power_175: sensor.lux_baxxxxxxx_battery_flow_live
grid_connected_status_194: binary_sensor.binary_on_grid
inverter_status_59: none
day_battery_charge_70: sensor.lux_baxxxxxxx_battery_charge_daily
day_battery_discharge_71: sensor.lux_baxxxxxxx_battery_discharge_daily
battery_voltage_183: sensor.lux_baxxxxxxx_battery_voltage_live
battery_soc_184: sensor.lux_baxxxxxxx_battery
battery_power_190: sensor.lux_baxxxxxxx_battery_flow_live
battery_current_191: none
grid_power_169: sensor.grid_power
day_grid_import_76: sensor.lux_baxxxxxxx_power_from_grid_daily
day_grid_export_77: sensor.lux_baxxxxxxx_power_to_grid_daily
grid_ct_power_172: sensor.lux_baxxxxxxx_grid_flow_live
day_load_energy_84: sensor.lux_baxxxxxxx_power_from_inverter_to_home_daily
essential_power: sensor.lux_baxxxxxxx_home_consumption_live
nonessential_power: none
aux_power_166: none
pv1_power_186: sensor.lux_baxxxxxxx_solar_output_array_1_live
pv2_power_187: sensor.lux_baxxxxxxx_solar_output_array_2_live
pv1_voltage_109: none
pv1_current_110: none
pv2_voltage_111: none
pv2_current_112: none
inverter_ac_temp: sensor.lux_baxxxxxxx_radiator_1_temperature_live
inverter_dc_temp: sensor.lux_baxxxxxxx_radiator_2_temperature_live
remaining_solar: sensor.solcast_forecast_remaining_today
CODE 2
type: custom:sunsynk-power-flow-card
cardstyle: full
show_solar: true
inverter:
model: lux
modern: false
auto_scale: true
battery:
energy: 19200
shutdown_soc: 5
show_daily: true
invert_power: true
colour: orange
auto_scale: true
max_power: 3600
show_remaining_energy: true
charge_colour: green
solar:
colour: green
show_daily: true
mppts: 2
display_mode: 2
pv1_name: Back
pv1_max_power: 2520
pv2_name: Front
pv2_max_power: 3360
auto_scale: true
dynamic_colour: true
efficiency: 3
load:
show_daily: true
dynamic_colour: true
dynamic_icon: true
grid:
colour: red
dynamic_colour: true
show_daily_buy: true
show_daily_sell: true
show_nonessential: false
invert_grid: true
no_grid_colour: grey
auto_scale: true
export_colour: green
grid_off_colour: grey
label_daily_grid_sell: Export
label_daily_grid_buy: Import
disconnected_icon: mdi:transmission-tower-off
export_icon: mdi:transmission-tower-export
import_icon: mdi:transmission-tower-import
entities:
day_pv_energy_108: sensor.lux_ba21360416_solar_output_daily
inverter_voltage_154: sensor.lux_ba21360416_grid_voltage_live
load_frequency_192: sensor.lux_ba21360416_grid_frequency_live
inverter_current_164: none
inverter_power_175: sensor.lux_ba21360416_battery_flow_live
inverter_status_59: sensor.lux_ba21360416_status
day_battery_charge_70: sensor.lux_ba21360416_battery_charge_daily
day_battery_discharge_71: sensor.lux_ba21360416_battery_discharge_daily
battery_voltage_183: sensor.lux_ba21360416_battery_voltage_live
battery_soc_184: sensor.lux_ba21360416_battery
battery_power_190: sensor.lux_ba21360416_battery_flow_live
grid_connected_status_194: binary_sensor.binary_on_grid
battery_current_191: none
grid_power_169: sensor.grid_power
day_grid_import_76: sensor.lux_ba21360416_power_from_grid_daily
day_grid_export_77: sensor.lux_ba21360416_power_to_grid_daily
grid_ct_power_172: sensor.lux_ba21360416_grid_flow_live
day_load_energy_84: sensor.lux_ba21360416_home_consumption_daily
essential_power: sensor.lux_ba21360416_home_consumption_live
nonessential_power: none
aux_power_166: none
pv_total: sensor.lux_ba21360416_solar_output_live
pv1_power_186: sensor.lux_ba21360416_solar_output_array_1_live
pv2_power_187: sensor.lux_ba21360416_solar_output_array_2_live
pv1_voltage_109: none
pv1_current_110: none
pv2_voltage_111: none
pv2_current_112: none
inverter_ac_temp: sensor.lux_ba21360416_radiator_1_temperature_live
inverter_dc_temp: sensor.lux_ba21360416_radiator_2_temperature_live
remaining_solar: sensor.solcast_pv_forecast_forecast_remaining_today
energy_cost_sell: sensor.agile_current_export_rate
energy_cost_buy: sensor.agile_current_import_rate
environment_temp: sensor.met_office_buntingford_temperature_3_hourly
